A Drop of Water

Walking along Newark’s Pequannock Aqueduct from source, to tap, to sewer

.

The general public views rural, suburban, urban, and industrial areas as being separate with different land uses, populations, and landscapes. The rural reaches and forests of northwestern New Jersey exist outside the imagination of Newark residents, as if these green mountain lakes with WASPy names have nothing to do with their lived urban experiences in the concrete and asphalt jungle. For the suburban and rural residents of West Milford, Ringwood, Wanaque, Bloomingdale, Kinnelon, Rockaway, Jefferson, Hardyston, and Vernon where Newark’s water supply originates, the experiences and troubles of Newark seem similarly distant, as if the quality of their forest oasis has nothing to do with the health outcomes of Newark residents. However, Newark’s century-old system supplies a half million people with some of the cleanest water in the country and invisibly knits together the fates of diverse communities along its buried path.

.

Handmade drawing of Newark’s Pequannock water supply system, dated December 1892
The red line traces the path of the aqueduct from start at the Macopin Intake to end at South Orange Avenue. Green is the area of the watershed. The red graph beneath charts the relative height of the aqueduct above sea level at each point in the route. The aqueduct does not flow in a continuous downhill slope. Rather it hugs the ground just below the surface.

.

Map of Newark water supply system in 1946, showing the Pequannock system opened 1892 (lower left) and Wanaque system opened 1930 (upper left). View full size map from Newark Public Library website.

.

Over winter 2021, I documented the route of the Newark aqueduct from its origins in West Milford Township to its terminus in Newark Bay. I trace the path of Newark’s 26-mile-long aqueduct and 63-square-mile Pequannock Watershed and 94-square-mile Wanaque Watershed on the interactive map below.

.

Click on water features to display details of name, dimensions, or volume.

■   Watersheds
■   Reservoirs (7 total)
~~ Aqueducts (~55 miles total)

■   Towns supplied with Newark water (~10)
■   Towns relying on Newark sewers (48)
~~ Main sewer interceptor (~ 28 miles total)
      Along path of Passaic River from Paterson to New York Harbor via Newark

.

When American cities started gathering millions of woodland acres and building hundreds of miles of aqueducts in the nineteenth and early twentieth centuries, water supply was an expensive undertaking and a point of civic pride. The opening of New York’s first water supply of the Croton Aqueduct in 1842 was the largest and most expensive project by a single city in American history. Exactly ten years earlier, New York City suffered its deadliest cholera epidemic due to poor sanitation and foul water, which left 3,515 dead out of a population of 250,000. (The equivalent death toll in today’s city of eight million would exceed 100,000.) With recent memories of death and trauma on New Yorkers’ minds, the opening of the city’s water supply was a public holiday with parades the length of lower Broadway and a giant fountain erected in front of City Hall. Along the new aqueduct’s path, brick and granite gatehouses, stone markers, and aqueducts modeled after those of Rome and antiquity advertised the otherwise invisible presence of the investments made below. Many of the sites along the route became tourist attractions in their own right with the weekend carriage crowd riding uptown to the future sites of Central Park and the New York Public Library. There they soaked in nature and appreciated the austere beauty of towering dams and powerful gates that released water downstream.
With similar fears of industrial contamination and water-borne disease, Newark’s water supply opened decades later in 1892. Like New York City, Newark was suffering from bouts of cholera for decades. Manufacturers in the “silk city” of Paterson upstream polluted Newark’s water supply downstream on the Passaic River. Unwilling and unable to invest in cleaner supplies from distant locations as New York City had done decades earlier, Newark suffered 107 typhoid deaths per 100,000 people in 1890. Fearing future death and predicting massive population growth, Newark leaders and industrialists (among them the city’s dozens of beer brewers who needed clean water) demanded change. At the cost of six million dollars, building a clean water supply at the Pequannock Watershed was the largest and most expensive project in Newark history, more than two times the size of the city’s 2.5 million dollar annual budget. Like the Croton system designed for one million customers when Manhattan had only had 330,000, Newark’s Pequannock water supply was designed for over 500,000 customers in a city of only 250,000. The Wanaque System was added by 1930 at a cost of 25 million, more than doubling the water available to Newark. Along the path, brick gatehouses and buildings dressed as neoclassical villas guided the flow of water. The image of Newark’s water supply is, therefore, as much a reflection of where the city was as a prediction of what the city would become. The external ornament and attention to quality materials invested in Newark’s water in the nineteenth and early twentieth centuries reveal the novelty of the technology, and the fact that for centuries Americans could not take clean water for granted.
After the September 11 attacks, and even for decades earlier, the presence of sensitive water supply infrastructure is no longer openly advertised. The razor wire perimeter fencing and warning signs that now surround Newark’s water supply hint at society’s evolving relationship with the land. The architecture once designed to welcome visitors is now closed off and patrolled by guards and security cameras for fear that people would poison their own water. Swimming and powered motorboats are both prohibited in Newark’s watershed for fear of pathogens and oil slick seeping into drinking water. The above ground features of the underground aqueducts are no longer proudly labeled with carved stone, as they would have been a century ago. The public assets that once belonged to society at large still belong to the public, but their existence is now opaque and hidden away for its own safety. The six billion dollars and fifty years New York City spent building “Water Tunnel No. 3” has no visible fingerprints above ground even though it is the largest water infrastructure project in American urban history. The public passes by unaware of how their tax dollars are spent behind the unmarked bombproof and airtight doors that guard the water tunnels carved 500 feet below. Newark is little different.

.

April 1892 plans of the Macopin Gatehouse. The original water supply to Newark was so clean that the water was unfiltered. As water quality standards increased and as runoff from new suburban development encroached on the watershed, this gatehouse was demolished for the water treatment facility now here.

.

Humanizing the 2,000 square mile watershed and aqueduct system that provides nine million New Yorkers with the cleanest water in America, architectural photographer Stanley Greenberg writes in Waterworks: A Photographic Journey through New York’s Hidden Water System:
Soon I came to think of the system as an underground organism, like the giant fungus now regarded as the largest living thing on earth. [….] Eventually I became able to ‘sense’ the water system. Sometimes it was because of the way the road was paved, or the type of fencing along the roadway. I knew which buildings were part of the water system, whether or not they were marked.
Along the path of Newark’s aqueduct, features are still visible above ground. From little bends in the road to the occasional barbed wire fence, one can “sense” the downward flow of water to Newark. In the lakes and streams of Newark’s watershed, the water supply is left uncovered. The water flows its natural course downstream in the prehistoric riverbed as it has since the Ice Age. At the Macopin Intake in West Milford, the towering mass of a windowless brick building intercepts the pristine river and sucks the water in to be treated, chlorinated, and injected with a cocktail of chemicals. Now sanitized, the water is piped the rest of the way underground. Any new contamination after this point would endanger thousands of lives. Contamination and pollution are existential threats facing any water supply. A few miles further down, the aqueduct skirts under the abandoned location of Nike Missile Site NY-88, an abandoned Cold-War era military installation to intercept nuclear missiles from Communist countries “hostile to American values.” The pair of four-foot diameter brick, iron, and steel conduits snake their way 280 vertical feet downhill at the average rate of about ten vertical feet for each horizontal mile travelled. The water passes beneath roads, golf courses, and green lawns of unsuspecting suburban residents. In some parts, the aqueduct is encapsulated in a raised dirt embankment. Walking along the raised dirt road offers views over fences into the freshly mowed lawns, garages, and children’s swing sets of suburban families unaware that the lifeblood of a half million urban people passes beneath their feet. At the occasional interval, a metal pipe painted green with a mushroom shaped cap points out of the ground. The little green pipes relieve pressure and aerate the water to keep it fresh. Putting one’s ear to the pipe as if it were a stethoscope, the throbbing pulse of flowing water is faintly audible. At other points, a mysteriously vacant but well-maintained lot on a street full of expensive homes hints that something is off. The presence of signs warning of the inexplicably steep $500 fine for illegal dumping and the absence of realtor signs selling this land reveals that something unnamed and important must flow beneath. Nearby, occasional road markers are spray-painted blue on the asphalt so that new roadwork does not accidentally puncture the aqueduct when digging. There are at least five streets in different towns all named in honor of what is buried beneath: Pipeline Path in Pompton Lakes, Aqueduct Avenue in Pequannock, Reservoir Drive in Woodland Park, Reservoir Drive in Cedar Grove, and Reservoir Place in Belleville. The aqueduct continues borrowing under Wayne, Totowa, Nutley, Belleville, and a handful of monotone suburbs known to most people only as the names of numbered exits on the highway.
As the water nears its destination, the suburban landscape visibly changes to the empty lots and corner bodegas of inner city Newark. At this point, the main aqueduct gradually narrows as smaller pipes splinter off at each intersection to serve the city’s approximately 30,000 addresses. Finally, at the intersection of South 8th Street and South Orange Avenue, the old aqueduct ends at the “Reservoir Site Townhouse Development.” The name of this privately owned public housing project is the only remaining hint of the former use of this site, where a sloping brownstone embankment once stored nine million gallons of water. Across the street, a three-floor brick water quality testing lab with limestone details has a neoclassical entrance with the words carved above: “Bureau of Water: Meter Laboratory.” The water-testing lab was abandoned and is now a non-governmental community health center. The loss of these public assets, and the neighborhood’s gradual population loss, hints at the larger retreat of government responsibility for protecting the public. While water was once a public asset advertised with civic architecture, the responsibility for water supply – and, with this responsibility, the health of thousands of water customers – is now tasked to semi-private and for-profit agencies that charge higher rates. The name of these water multinationals slip off the tongue and sound like the kind of slick words a team of consultants from the Wharton Business School would dream up: Veolia, Suez, Aqua America, and Aquarion Water. New Jersey, Idaho, and Connecticut, in fact, rank highest in the country for the percentage of their public water supply that is privatized, over 35%.
Running a few feet beneath each water line is the wider pipe of the city sewers. The two systems run in concert with each other, one whisking in fresh water and the other flushing wastewater away sight unseen. Rainwater from city streets mixes with the polluted water of houses and businesses and continues flowing over 230 vertical feet downstream to Newark’s sewage treatment plant in the meadowlands. Over thirty miles from where it entered the system, the water exits the system as it entered it—through the vast and chemical-intensive technologies of water purification. The brown slurry is pumped into basins the shape and depth of a swimming pool, where solid matter settles to the bottom. The remaining water is pumped off into treatment tanks resembling the steel drums used to store vast quantities of propane and natural gas. It is strange that Newark’s facility for water decontamination should be so close to and look so similar to the gas storage tanks of Shell Oil across the street, a company responsible for untold water contamination and environmental destruction. Down the street is the county jail where immigrants and inmates are incarcerated as a source of income for the Essex County government. In a fitting irony, much of the $42.7 million revenue generated from the county jails in 2019 was pumped back upstream to maintain and preserve the county’s hundreds of acres of parks, forests, and mountain lakes. One jail visitor writes: “There’s more drugs in there than on the street. It is located right across the street from a garbage dump. The smell in the air, especially in the summer, is absolutely rancid.” In a fitting twist of fate, the source of Newark’s water supply on a quiet country road with McMansions in West Milford and the destination of this water in an industrial wasteland are both named Doremus Road and Doremus Avenue, respectively, in honor of the Newark mayor responsible for building the system over a century ago.
Water trickles down from the wealthy bedroom communities of northern New Jersey through progressively less wealthy towns, through the low-income community of Newark, and finally past the jail where society’s weakest members and immigrants are held captive. More than a few of these immigrants, no doubt, lived nearby and commuted out to the affluent suburbs to work on the green lawns and sewer systems whose effluent returns to Newark and which they must now smell in jail. At least 200,000 of these white-collar workers commuted in to Newark pre-pandemic, and extract their wealth from this city. From many of their backyards laced with fertilizers and insecticides, water returns to Newark. As the warning on many a suburban manhole reads: “No Dumping Drains to Waterway.” We live in a society deeply divided on fault lines of income, race, and location. The journey of Newark’s water through diverse communities is a reminder that, however divided and segregated our society, the need and the right to water cuts across lines of class, race, and geography. This ends our journey from rural to urban through the suburban landscape of New Jersey.

.

Newark water supply air valves, June 1892

.

Related

A history of the Wanaque water supply from the Wanaque Public Library
A history of the Newark water supply from the Newark Public Library

Homesteads to Homelots

The history of New Jersey suburbs as told through five data visualizations

.

View of the city from the suburbs, author’s panoramic drawing of suburbs with urban skyline in the far distance

.

“The state of New Jersey offers an ideal setting in which to analyze the distinctive residential landscape of mass suburbia. [….] In time, 70 percent of the state’s total land area would qualify as suburban, so that by the turn of the twenty-first century New Jersey and Connecticut shared the distinction of being the nation’s most suburbanized states.”

.

– Lizabeth Cohen, “Residence: Inequality in Mass Suburbia” in A Consumer’s Republic, p. 197.

.

Northern New Jersey has long been central to the history of America’s suburban growth. From America’s oldest suburban developments to its most homogeneous to its most diverse, New Jersey’s 565 municipalities span the full portfolio of suburban living arrangements. New Jersey is unique in the sheer number of municipalities, each with its own elected leaders, school district, police, fire, and land use policies. As a result of inefficient and often duplicate public services in competing suburbs, New Jersey has some of the highest property taxes and cost of living in the country. This problem is not unique to New Jersey; it affects the country at large in dozens of other places. The story of one region makes for a powerful and revealing case study of larger stories in American urban history.
This analysis examines New Jersey census data from 1940 to 2010. It not the end point or a full analysis. Instead, each of these data visualizations plots a direction for future research. Telling history through methods of map making and analysis of census data make it possible to tell the history of a larger region and country.

.

Method

With data from the US Census Bureau, I extracted details on the population of every New Jersey municipality from 1940 to 2010, the period of greatest suburban sprawl. With spatial data on municipal boundaries from the NJ Office of GIS, I plotted the census data onto the map of municipal boundaries. This allowed me to see spatial patterns and to produce heat maps of population change over time. The spatial data also revealed the surface area of each municipality, which allowed me to calculate the historical population density of each municipality as a function of population divided by surface area. You can browse all the data visualizations or download the open source data here from Tableau. These data visualizations represent analysis of approximately 13,560 data points for 565 municipalities over eight censuses.

.

1. Population loss vs. gain

.

The map below reveals that every urban area in New Jersey lost population from 1950 to 2000. Meanwhile, the majority of rural areas gained population to become commuter suburbs. Wedged between the metropolises of New York City with 8.4 million residents and Philadelphia with 1.6 million, New Jersey has no cities with over 300,000 people. Thousands of white-collar workers live in the state’s suburbs and commute out of state for work, at least a quarter million people per weekday pre-pandemic. New Jersey is therefore more of a bedroom community than any other American state. The map below shows the scale of suburban population growth with areas that gained population colored in green. The darker the shade of green the greater the population gain from 1950 to 2000. At the same time, almost every major New Jersey city was losing people. The darker the shade of red the greater the population loss. This map produces two parallel stories of urban decline vs. suburban growth.

.

Hover over data points to reveal details.

.

Unsurprisingly, the rural parts of the state with the farthest commuting distance from New York City and Philadelphia experienced the least population growth. Instead of becoming suburbs, the farmlands in the northwestern corner of the state that once provisioned New York City markets with food reverted to forest during the twentieth century. At the same time, Central Jersey’s richest and most fertile farmland along the Northeast Corridor became suburbs. The farms here were pushed farther away, such that, by the end of the twentieth century, New York City food is supplied from thousands of miles away. The state’s nickname of the “Garden State” once referred to the state’s rich agriculture and farms. Today, this name has an unintentional double meaning, as the only gardens left are the green suburban lawns in the ever-expanding crabgrass frontier.

.

2. Link between population densities and suburban growth

.

From 1950 to 2000, a total of 52 New Jersey cities lost about one million white residents and gained about 400,000 Blacks and Hispanics. As whites moved out, other ethnic groups moved in. The flight of urban whites to the suburbs happened across twentieth-century America.
In contrast to the population decline of New Jersey cities, a total of 513 towns and boroughs gained around four million people from 1950 to 2000. New Jersey’s suburban population growth was through a combination of whites arriving from cities, whites arriving from other states, and the natural birth rate during “baby boomer” generation. The average population density per square mile of places that lost people in this period was 6,400, while places that gained people contained on average 2,100 people per square mile. New population growth has been occurring in once rural areas that historically had low population densities. In other words, sprawl. Almost all of New Jersey’s population and economic growth in the second half of the twentieth century was concentrated in lower-density suburban areas, often at the expense of the cities where wealth was traditionally concentrated.

.

Hover over data points to reveal details.

.

Horizontal axis ranks places by population loss or gain (logarithmic scale). Vertical axis ranks places by population density in 1950 (linear scale). Dots are sized according to population in 1950. Red dots are, on average, larger cities that lost population. Green dots are, on average, smaller suburbs that gained population. All the largest cities with the higher population densities, that is, all the largest dots (with the exception of Union City) lost population to neighboring suburbs. The higher the population density, the greater the magnitude of twentieth-century population loss due to decentralization. Notice how high-density cities with large populations form one red cluster, while low-density suburbs with small populations form an entirely separate green cluster.

.

3. Resistance to municipal annexation

In the late nineteenth and early twentieth centuries, dozens of American municipalities were consolidated into larger urban areas. For instance, the 1898 consolidation of Manhattan, Bronx, Brooklyn, and dozens of small farming hamlets in present-day Staten Island and Queens produced the contemporary city limits of New York City. This 300 square mile area allowed for New York City’s urban expansion, the elimination of otherwise duplicate municipal services, and the central organization of rapid transit, zoning, and land use policies. The metropolitan-scale vision and infrastructure projects of Robert Moses would have been impossible otherwise.
Municipal consolidation never went as far in New Jersey, with only a few exceptions. The state’s second largest city of Jersey City with a population of 266,000 (2018) was formed in 1870 by merging the small towns of Hudson City, Bergen City, and Greenville. The state’s largest city of Newark with a population of 282,000 (2018) was reformed in 1905 by annexing neighboring Vailsburg. But as a whole, the state remained geographically divided with its largest cities unable to increase in population or expand their political power through municipal annexation. Throughout much of the nineteenth century, and even before the era of rapid suburban growth, the trend in New Jersey was already toward decentralization with the subdivision of larger towns into ever-smaller units and school districts. For instance, if Newark covered the same surface area in 2019 as it did in 1790, it would be the eighteenth largest city in the US in 2019 with an estimated population of 800,000, ahead of Denver and behind Seattle. Instead, Newark is the country’s third oldest city behind Boston and New York, but is only the 73rd largest in population. Suburban towns straddle it on all sides, isolating a majority Black community in the inner city from the prosperity of surrounding suburbs. In contrast to cities in most other developed countries, American cities are largely concentrations of poverty ringed by wealthier areas.
Cities like Newark rank higher in their regional and economic influence than their small populations and limited surface area would lead one to believe. Newark is the state’s economic, shipping, rail, airport, and higher education hub, with more of these key industries concentrated in Newark than in any other New Jersey city. But suburban policies resistant to centralized government and municipal annexation have thwarted Newark’s deserved political influence. Kenneth Jackson describes consolidation in Crabgrass Frontier: “Without exception, the adjustment of local boundaries has been the dominant method of population growth in every American city of consequence. [….] Viewed another way, if annexation had not been successful in the nineteenth century, many large cities would have been surrounded by suburbs even before the Civil War.”
Unfortunately, while the rest of the country was moving toward annexation in the nineteenth century, New Jersey experienced municipal fragmentation. For instance, the more urban and higher density borough of Metuchen is entirely surrounded by the less urban and lower density town of Edison. At one time, these two places were part of a single and larger township called Woodbridge. As newly opened railroads linked city and country in the mid nineteenth century, urban residents starting moving to Woodbridge and formed an early commuter suburb. The existing residents of Woodbridge were largely Democrat farmers, while the new commuters were largely Republican businessmen. The farmers were content with few municipal services, while the new commuters demanded paved roads, water supply, sewers, and street lighting. In the resulting conflict between rural and suburban, the small suburb of Metuchen clustered around its commuter train station broke off from the larger municipality. But at only 2.85 square miles, Metuchen is the size of postage stamp on the map of New Jersey. The shape of Edison is like a doughnut that surrounds Metuchen on all sides.
There are at least thirty towns like Metuchen across the state, known as “doughnut towns” because one municipality entirely surrounds another. The average size of these towns is less than three square miles. This unique quirk of New Jersey geography hints at the longstanding conflict between rural and suburban. As the state evolved from a land of homesteads into a sea of platted suburban home lots, existing farmers resented anything even closely resembling the “urban” and “cosmopolitan.” In many other states, rural farmers went along with the newly arrived residents of commuter suburbs and accepted greater investment in municipal services. In New Jersey, rural residents did not; they insisted on autonomy, independence, and decentralized government. Hence, New Jersey splintered into so many hundreds of places with their own strong, separate, and long established civic identities. As a result, cities like Chicago and New York cover enough surface area that a Black or Hispanic family can move to a better neighborhood nearby without being in a new suburb. But New Jersey is so geographically fragmented that a change of address almost invariably means a change of town with new laws, new taxes, a new civic identity, and a new school district. The table below outlines these municipal enclaves.

.

Hover over data points to reveal details.

.

The county maps from John P. Snyder’s History of New Jersey’s Civil Boundaries are particularly revealing. They vividly illustrate the division of New Jersey into ever-smaller municipal units. The map below shows, for instance, the original and now contemporary municipal boundaries in Hudson and Bergen County along the Hudson River. Colored in green are original boundaries vs. the present-day ones in black.

.

.

4. The municipal fabric before suburban growth

New Jersey’s municipal framework for suburban growth was laid out early, even centuries before its suburbs grew. The earliest settlers and colonists in America believed in local control of government. In the New England farming hamlet of colonial days, all eligible white male taxpaying citizens participated in direct democracy. These voters were tasked with passing new laws, improving roads, and maintaining common lands. Over 200 years of early American growth, almost all of the land within the eight states of New Hampshire, Vermont, Massachusetts, Rhode Island, Connecticut, New York, Pennsylvania, and New Jersey were divided into “incorporated communities.” This produced hundreds of New England towns with relative autonomy from higher authorities.
By contrast, the rest of America followed a different development path from the original thirteen British colonies and contained more “unincorporated communities” – that is land and people not part of a local and direct democracy. People in unincorporated communities are still full citizens with voting rights, but the management of their municipal services, like roads and water, is often tasked to a larger and more distant power, like the county government. Several unincorporated villages might also be grouped as part of a larger municipality.
New Jersey’s belief in local control and direct democracy resulted in the early incorporation of municipalities, and a likely stronger sense of local identity than in other regions. The chart below shows that most of New Jersey’s municipalities were laid out in two sweeps. In 1798, 104 largely rural and farming towns were incorporated as part of the “Township Act of 1798.” Decades later, new residents in the state’s growing commuter suburbs demanded more municipal services like water, fire, and sewer. When residents of the existing farming areas objected, dozens of boroughs broke away to form bedroom communities in the second sweep of new municipalities incorporated. The peak year was 1894 when 36 new towns and boroughs were created along the commuter rail lines linking northern New Jersey to New York City. However, during the high period of suburban growth from the 1930s to the present-day when New Jersey gained 4.8 million people, a mere twelve new places were incorporated. In other words, the political geography of New Jersey suburbs was laid out entirely before the mass exodus of Americans from cities to suburbs in the twentieth century.

.

.

New Jersey’s anti-urban outlook and politics are no recent or twentieth-century phenomenon. Nor did these fears of central administration come about during the suburban age. In fact, the groundwork for New Jersey’s rapid twentieth-century suburban growth was laid in the state’s earliest days.

.

5. Conclusion: New Jersey is still in the suburban age

.

After 1980, thousands of Young Urban Professionals (“Yuppies”) returned from the suburbs to live in the cities. However, any post-1980 urban population gain was usually not enough to counter pre-1980 population loss. While a few smaller New Jersey cities regained earlier losses from 1980 to 2010, new population growth and new housing construction were concentrated in suburban areas on the whole. New Jersey cities have grown, but they are not growing as fast as the suburbs surrounding them.

.

Mixed results of “back to the city”

Color key
Urban growth since 1980 does not offset earlier losses
Urban population growth since 1980 offsets earlier losses
No net population loss 1950 to 1980

.

This table above shows that of the twenty-four largest New Jersey cities in 1950, sixteen had a net population loss from 1950 to 1980. In the period 1980 to 2010, only seven of these sixteen cities have seen population growth (Jersey City, Paterson, Elizabeth, Passaic, Hoboken, Perth Amboy, and Kearny). And even among these seven cities, only five of them have seen enough population growth to offset pre-1980 population losses (Paterson Elizabeth, Passaic, Perth Amboy, and Kearny). In addition, two of the twenty-four cities have even seen a higher rate of population loss from 1980 to 2010 than from 1950 to 1980 (East Orange and Irvington).
Viewed another way, of these twenty-four largest cities, only nineteen have seen an increase in the rate of population growth after 1980. But among these nineteen cities, population growth has always been from the replacement of whites with largely lower-income immigrants from Latin America. The only two cities yuppies and middle class whites were uniquely responsible for “turning around” through gentrification were Hoboken and Downtown Jersey City, both of which still had a net population loss from 1950 to 2010. Immigrants, more than wealthy young people, are the new drivers of urban growth in New Jersey.
The table below shows that New Jersey’s six leading cities of Newark, Jersey City, Paterson, Elizabeth, Trenton, and Camden were always majority white until 1950-1960 when thousands of whites fled for the suburbs. The demographic trend lines have not reversed. Only small numbers of younger and wealthier whites have returned to cities, which is not enough to offset the continued white flight to the suburbs. In other words, the urban population of New Jersey cities has stagnated since 1980. Population gains have been small, barely enough to offset continuing population loss. Because many cities have not made up for their earlier losses of people and economic power, the story of “Back to the City” can only be applied to a limited number of cities in New Jersey.

.

Hover over data points to reveal details. Hispanics not counted in graph because they were not measured on US census until 1970.

.

Hover over data points to reveal details. Hispanics not counted in graph because they were not measured on US census until 1970.

.

Taking these charts into account, Newark lost 330,000 whites from 1930 to 2000. Since then, population loss has slowed, but the city only gained 400 whites from 2000 to 2010, a drop in the bucket. In the same period of 1930 to 2000, Jersey City lost 222,000 whites, Paterson lost 90,000, Trenton lost 87,000, Camden lost 94,000, and Elizabeth lost 42,000. This brings the estimated white population loss of the state’s six leading cities to about 866,000. If including smaller places that also lost their white population, such as Union City, Clifton, Atlantic City, and Plainfield, the urban population loss comes to well over one million people. At the same time, the population gains these cities saw in Blacks and Hispanics have not been as large as the population loss. Cities across New Jersey are smaller and less economically central than they were a few decades ago.
Despite construction of new light rail systems and improvements to existing rail infrastructure, over 80% of New Jersey residents still commuted to work by car. Even in Hudson County, with excellent transit connections in Hoboken and Secaucus, 66% of commutes were still by car in 2000. New Jersey might be rich in transportation options and railroads, but most of its built environment of sprawling suburbs was not built with these “urban” transit modes in mind.
In other words, the image “Back to the City” with young people riding on bikes and public transit is more of a New York City story than it is a Trenton, Newark, Camden, or Atlantic City story. “The Garden State” was and remains suburban despite surface appearances of a renewed interest in cities. As economic historian Leah Boustan writes in Competition in the Promised Land: “Even though black in-migration to northern cities has tapered off, relative black wages have not rebounded in the North and white flight has not reversed course (despite media reports of a ‘return to the city’)” (p.9). Much of the public thinks that young people prefer to live in cities, and that the age of suburban sprawl is over in the age of the climate crisis. But two centuries of urban growth have failed to turn New Jersey into a state whose residents think of themselves as urban, even though it is an integral part of greater New York City. The path of decentralization that New Jersey has followed for two centuries will likely guide it for decades more.
Is “Back to the City” part of a larger cultural shift, or is it merely a short-term illusion that the pandemic reversed when thousands of high-income young people moved back to the suburbs? If the history of New Jersey is any guide, the suburbs are alive and well and here to stay.

.

Levittown, America’s most famous mass-produced suburb, was replicated in Pennsylvania, Long Island, and New Jersey

.

Sources

All Municipalities:

Population of all municipalities from 1940 to 2000, from NJ State Data Center report (table 6, p. 26-51)
Shapefile of municipal boundaries with 2010 population of each municipality, from NJ open data
List of municipalities by year incorporated, from Wikipedia

Three data sources above are merged into these visualizations, posted to Tableau for free download

.

Six Leading Cities:

Populations and races of NJ’s six largest cities from 1810 to 1990, from US Census Bureau working paper (table 31, p.78-79) and this documentation page
Populations and races of NJ’s six largest cities for 2000 and 2010, from Census Viewer website because above table was only up to 1990

Two data sources above are merged into this visualization, posted to Tableau for free download

.

Other Sources:

NJ population density map, from Census Viewer website
Analysis of transportation patterns, from NJ Department of Transportation report
Satellite imagery of the entire state in 1930 offers a comparative view of the largely rural state before suburban sprawl, from NJ Office of GIS

John P. Snyder. The History of New Jersey’s Civil Boundaries, 1606-1968. Trenton: Bureau of Geology and Topography, 1968. (link)

Book Review of “Saving America’s Cities”

Lizabeth Cohen. Saving America’s Cities: Ed Logue and the Struggle to Renew Urban America in the Suburban Age.
New York: Farrar, Straus and Giroux, 2019. 547 pp.

.

The memory of mid-century urban renewal will always evoke images of the bleak brick towers and windswept plazas of crime-ridden public housing. Urban renewal projects airdropped into the city fabric caused demolition and dislocation. This colossal failure has been epitomized by Robert Moses’ automobile-oriented vision of New York City. The Power Broker by Robert Caro described Moses stubbornly going alone to remove 1,500 families and pave the Cross Bronx Expressway through their vibrant neighborhood.[1] By contrast, in The Death and Life of Great American Cities, Jane Jacobs vividly described a sentimental city life with lively streets of safe neighborhoods. Pedestrians stroll along short city blocks while residents watch from brownstone stoops in her quaint Greenwich Village alleys.[2] The two polarized visions of activist Jacobs vs. authoritarian Moses have effectively set the terms of the debate on city design and, by extension, about the government’s role in structuring urban life. Lizabeth Cohen, a Harvard historian of twentieth-century America, critiques the current dichotomy: “The lack of subtlety that I have lamented in current historical understanding of postwar American urbanism stems partly from its frequent framing as a monumental battle between the clashing visions of the villainous Robert Moses and the saintly Jane Jacobs.”[3] Between these two schools of thought, Cohen introduced the largely forgotten “Master Builder” Ed Logue to dispel misconceptions about urban renewal.
Logue serves a curious alternative to the polarity between Jacobs and Moses. Despite her biographical focus, Cohen does not lionize Logue’s dedication, but recounts his lifetime of successes, false starts, and imperfections. Logue came from a Philadelphia working-class family with an Irish Catholic background. Serving as a bombardier during WWII, he first experienced a top-down city vision from the air above Berlin and Dresden. Trained at Yale with a full scholarship, Logue was committed to the New Deal idealism of government serving the public good. His life, however, demonstrated how even the best of planners could not get the ill-conceived legal framework behind urban renewal to work most of the time. One reviewer of Cohen’s book asks in Architect Magazine: “How could such a clear-eyed, honest, and progressive guy, talented at getting lots of money from the federal government, oversee so many disastrous projects?”[4]
Through New Haven, Boston, and New York City, Cohen traces Logue’s city planning career of working against far larger anti-urban political and social forces. During his time in New Haven (1954-60), Logue planned to rescue the falling city by bringing suburban shoppers downtown. He built the Oak Street Connector for shoppers’ automobiles. This highway stub severed the urban fabric with an asphalt band of parking lots and uprooted a largely low-income black community. However, Logue’s Chapel Square Mall in downtown New Haven, with indoor shopping and garage parking, never brought in enough enthusiastic suburbanites to survive against competing forces of anti-urban decentralization. What Logue called a “pluralist democracy” in New Haven planning actually relied more on experts’ work than on input from affected citizens.
Touting his approach of “planning with people,” Logue worked in Boston (1961-67) to break the city’s thirty-year economic stagnation. Unlike in New Haven, Logue created a “negotiated cityscape” of old and new in Boston and preserved some of the oldest architecture, such as Quincy Market. However, his ambitious Brutalist inverted ziggurat of the Government Center, next to a desolate brick-paved plaza, evoked an oppressive aura. His successful housing projects, particularly in the African-American Roxbury neighborhood, defied James Baldwin’s characterization that “Urban Renewal means negro removal.”[5]
Logue’s next career move (1968-75) landed him in New York City to lead the Urban Development Corporation (UDC) for 33,000 residential units, including thousands of affordable housing. After the “long, hot summer of 1967” with riots in 159 cities, President Nixon formulated his “suburban strategy,”[6] by appealing to suburban whites’ fears of the inner city and black insurrection. In a hostile climate, Logue encountered his political match from suburban residents. The wealthy Westchester towns vehemently opposed Logue’s attempt to place middle income and affordable housing in their backyard. The downward spiral of urban America became unstoppable. Neither urban renewal, nor affordable housing, nor highway construction could restrain the core middle urban tax base from driving away to the alluring American dream of “little boxes on the hillside,”[7] with “a chicken in every pot and a car in every garage.”[8]
Ousted from UDC, Logue settled for the final stage of his career (1978-85) at the South Bronx Development Organization. To revive the South Bronx with affordable housing, Logue no longer turned to demolition, as the urban fabric had already been devastated by arson, blight, and white flight. Logue recognized that the government had ceased investing in shopping malls, city halls, or intensely designed architecture. Instead, as if admitting the defeat of high-density urban development, Logue worked with residents to rebuild formerly urban Charlotte Street along suburban models of prefab homes with white picket fences. In a thriving nation of suburbs, the suburb had now come to the city.
Logue’s career capstone in the South Bronx was not polished architecture that he preferred, but the development that people desired. Community participations brought all stakeholders to the table, as Logue increasingly practiced. Over time, he realized that the top-down approach taken by urban redevelopment experts had serious limitations. People in the affected neighborhoods deserved to realize their vision of urban communities diversified with respect to income, race, and age. Their voices were the best insurance for equitable services for schools, transportation, retail stores, and affordable housing.
As Cohen asserts, Logue and urban renewal defy fast judgments. Across each decade, and in each of those three cities, Logue’s urban renewal had shifting goalposts, developed at various scales, and involved different levels of community participation. To attribute the flaws of urban renewal to arrogant individuals or to austere designs for “towers in the park” is to ignore the larger picture. As Logue’s battle for affordable housing in suburban Westchester revealed, the problem rests less with urban renewal itself and more with the nation’s social, economic, and political agenda against cities.
Throughout his career, Logue’s honorable goals proved impossible. With the Cold War fever in the ‘50s, the erosion of social tenets in the ‘60s, and post-Watergate suspicions against authority in the ‘70s, American public ceased to believe government had a mandate to bring about a just and equitable society. In his 1981 inauguration address, President Reagan expressed the core of the conservative belief: “In this present crisis, government is not the solution to our problem; government is the problem.”[9] During his final years, Logue watched helplessly as America increasingly turned to private investments for deteriorating infrastructure, eroding affordable housing, and shrinking essential services. Contemporary cities are defined by accumulated wealth, racial disparity, and privileged consumption. Even with Section 8 vouchers and “inclusionary” zoning, affordable housing is largely unavailable to diverse communities.[10]
The intriguing story of Logue’s life suggests that the fate of cities cannot be left solely to top-down developers or government bureaucrats or market forces. A process of negotiation is needed in order to bring all interests to the table. A spirit of experimentation defies an authoritarian way to remake cities. Paradoxically, to respond to a national emergency, Logue, a lifelong New Dealer, believed that the federal government’s pivotal role is essential for successful negotiations and experimentations. This would be the legacy of urban renewal, as Cohen concludes, that “the master builder” would want us to honor.

.

Endnotes

[1] Robert Caro, Robert Moses and the Fall of New York (New York: 1974).

[2] Jane Jacobs, The Death and Life of Great American Cities (New York: 1961).

[3] Lizabeth Cohen, “Saving America’s Cities: Re-evaluating the complex history of urban renewal,” Public Seminar, October 1, 2019. https://publicseminar.org/essays/public-seminar-excerpt-and-interview-lizabeth-cohen/

[4] Elizabeth Greenspan, “Ed Logue and the Unexpected Lessons of Urban Renewal: A biography of the forgotten ‘master rebuilder’ challenges established truths about city planning,” Architect Magazine, January 29, 2020. https://www.architectmagazine.com/design/ed-logue-and-the-unexpected-lessons-of-urban-renewal_o

[5] James Baldwin interview with Kenneth Clark, 1963. https://www.youtube.com/watch?v=T8Abhj17kYU

[6] Matthew D. Lassiter, The Silent Majority: Suburban Politics in the Sunbelt South (Princeton: 2006).

[7] From the song “Little Boxes” written by Malvina Reynolds in 1962, sung by Pete Seeger in 1963

[8] From Herbert Hoover’s 1928 presidential campaign slogan

[9] “Ronald Reagan Quotes and Speeches,” Ronald Reagan Institute. https://www.reaganfoundation.org/ronald-reagan/reagan-quotes-speeches/inaugural-address-2/

[10] Kenneth Jackson and Lizabeth Cohen, “Urban Renewal in the Suburban Age: The Struggle to Redefine the American City,” Brooklyn Public Library: Center for Brooklyn History, October 23, 2019. https://www.brooklynhistory.org/events/urban-renewal-in-the-suburban-age-the-struggle-to-redefine-the-american-city/

The time-lapse history of Manhattan in two minutes

.

This two minute time-lapse reconstructs the 400 year evolution of Lower Manhattan’s skyline. Watch as the city evolves from a small village into a glistening metropolis.
This is also a film about the history of technology. Changing methods of representing urban space influence our perception of time and the city. When New York City was founded, Dutch settlers captured their town’s appearance through seventeenth-century drawings and paintings. As the city grew, people started using printing presses to reproduce images of the city in the eighteenth and nineteenth centuries. In the twentieth century, photographers started capturing their city from above through aerial photos. For the first time, New Yorkers could view the entire city in a single panoramic photo.
In tribute to this long artistic tradition, this film constructs the city as each generation of New Yorkers would have represented it: through the subsequent technologies of drawing, printing, photography, and film.
.
New York City: Past and Present, 1870 and 2017

.

Sound effects from Freesound
Water and cloud effects from YouTube

Demolishing Public Space at New York Penn Station

What does old Penn Station’s loss reflect about the evolution of public space in New York City?

With assistance from Evander Price, recent PhD student in American Studies and chronocriticism at Harvard University. Thanks also to Adam Brondheim for his insights about historic preservation in NYC.

.

Download this essay as a PDF file

.



The old waiting room, [1] once the largest indoor public space in New York City, is now a parking lot. [2]

Demolition crews began hacking away at the limestone walls, stone eagles, and thirty-foot tall Doric columns of old New York Penn Station in October 1963. In a construction industry where architects typically quote projects as lasting eighteen months, the demolition and rebuilding of old Penn Station lasted five years. At its 1910 opening, old Penn Station was the largest and most expensive infrastructure project ever built in New York City. The station’s associated service tunnels stretched 5.5 miles under the Hudson and East River. At 350 feet long and 150 feet high, old Penn Station’s waiting room was the city’s largest internal space. Construction cost $100 million, or $2.7 billion in 2020 adjusted for inflation. By 1963, this was the largest and most expensive structure ever demolished in New York City.[3]
In a 1963 conversation with The New York Times, the developer justified demolition as “putting passengers first” and then clarified: “The outside is the only thing of artistic value as far as I’m concerned. The handling of 200,000 passengers is much more important to me. […] In some areas the land is just too valuable to save anything that doesn’t fully utilize it.”[4] The developer’s aspirations for Penn Station’s replacement, however misguided, were no less monumental in their imagination: to construct a profitable office skyscraper and Manhattan’s largest arena for sporting events and conventions. Office workers and event spectators could move directly from trains to their seats without stepping outside, or engaging with the public space of the city streets.

.

1968 advertisement for the new station [5]

.

“The fact is that the redevelopment of the Pennsylvania Station into a $90 million building complex will transform the area from a static uneconomic burden on the railroad into a viable commercial and recreational center of benefit to the entire West Thirty-fourth Street neighborhood and the public at large.” – Allen J. Greenough, Pennsylvania Railroad President.[6]

.

Architects have long positioned the demolition of monumental old Penn Station as a key moment in the discourse on historical preservation. This was, to quote leading New York City historian Kenneth Jackson, the moment when: “Human beings, myself included, have an unfortunate tendency to appreciate people and things only after they are gone. Pennsylvania Station is the catalyst for the historic preservation movement.”[7] The public realized that even a monument as expensive and permanent as Penn Station could vanish with no mechanism for the public to object. Activists pressured the city government to pass New York’s first ever landmarks preservation law in 1965.[8] Some historians, like Anthony Wood, have posited that the movement toward landmarks preservation began years before Penn Station’s demolition, and that this demolition was not critical in motivating landmarks preservation.[9] Nonetheless, in the following decades, the city protected over 120,000 historic buildings (comprising about 14% of New York City’s built environment).[10]
Less cited and discussed is how Penn Station’s loss parallels a larger late-twentieth-century trend to erode and privatize the commons. The demolition and rebuilding of old Penn Station is a lens to examine the competing tensions of economics vs. aesthetics and private vs. public interests. The demolition and reconstruction of old Penn Station mirrors the larger abandonment of government and corporate responsibility for maintaining and upholding public space.

.

Although Midtown’s largest building in this c.1911 photo, skyscrapers soon surrounded Penn Station.[11]

.

Old Penn Station as public space in a city of private interests

.

In a city symbolic of rational capitalism and industry, old Penn Station spoke of an alternative and idealistic vision for future New York: a city of low-rise buildings and ample public space. The station’s architects McKim, Meade, and White disdained New York’s emerging skyscrapers. They toured Europe in preparation for designing Penn Station. European models of wide and long boulevards framing monumental buildings inspired them, such as the Gare de l’Est in Paris. At the time, the average building in Midtown Manhattan was no higher than six stories, and Penn Station – at over 150 feet tall – would have been among the neighborhood’s highest and largest buildings. For inspiration, the architects copied the main waiting room from Rome’s Baths of Diocletian.[12] This reference is more than aesthetic: Rome’s massive baths were as much functional infrastructure in a city without widespread indoor plumbing as they were civic and social spaces for all people to gather and socialize. By analogy, the Pennsylvania Railroad envisioned its waiting room – which was far larger and cathedral-like than the functional operations of boarding a train demands – as a civic and social space, an urban stage-set for the drama of commuting. Andrew Carnegie, the industrialist turned philanthropist who launched his business career as an employee of the Pennsylvania Railroad, wrote in his 1889 article The Gospel of Wealth: “Surplus wealth should be considered as a sacred trust, to be administered during the lives of its owners, by them as trustees, for the best good of the community in which and from which it had been acquired.”[13]
Old Penn Station operated as public space that belonged to the city at large. Ingrained in a visit to the museum (with an admission fee), the public library (with set hours and borrowing rules), or the church (with a dress code and participation rituals) is the management’s expectations of how one is supposed to behave. The rules of these rarified spaces effectively narrow the social class and types of people who visit museums, libraries, and churches.[14] In contrast, the big city train station has fewer expectations of users. It is open at all times and to all audiences and social classes with effectively no restrictions. Like the restriction-free spaces of Times Square and the public park, the monumental rooms of old Penn Station seemed to belong to everyone. It was one of those unique spaces created entirely through private initiative, but where anyone could assemble in the shared experience of urban life.[15]
However, there was a crucial difference between normal public space and the “public space” of old Penn Station. The station was privately owned and subject to the whims of its owner who, unlike a government official responsible to the public, was duty bound only to company shareholders and employees. The public could use this station and construct it in the collective imagination as belonging to the city and the people, but the public’s use was at the property owner’s discretion. By the 1950s, the Pennsylvania Railroad was losing rail passengers to the increasing popularity of the automobiles, highways, and airlines. The company was bleeding money on old Penn Station’s upkeep to the sum of $3.3 million a year. Although the station’s appearance and location were effectively a public service and an enhancement to civic life for the thousands of commuters, there was no profit to be made from this form of public service.[16] In other words, with no “business model” for the space to pay for its own upkeep, old Penn Station gradually slipped into decay as the walls grew black from decades of soot and deferred maintenance.

.

Erosion of the commons

By the 1960s, the Pennsylvania Railroad’s reasons for maintaining old Penn Station started shifting when they argued that they could only support the commons so long as they did lose anything financially. The now aging and indebted railroad no longer had the “surplus wealth” to think of the public interest and the “good of the community” to borrow Carnegie’s words. In demolition proposals, the developer clarified that new Penn Station would be financially self-sufficient. Revenue generated from the new offices and arena above ground would support the upkeep of the station below ground, all the while generating surplus income to pay off the railroad’s debt. This is a frequent and often repeated claim among New York City developers: The creation and maintenance of public space must generate some profit. Or if no profit is to be made, the public should compensate the corporation for its gift. Hence, the lead redeveloper is quoted as saying about old Penn Station: “If anybody seriously considered it art, they would have put up some money to save it.”[17]
Old Penn Station had tall ceilings and, with no buildings above, ample natural light illuminated the interior. When the public saw this kind of space, they read it as open and public. When the owners of Penn Station saw this space in the 1960s, they read all this “empty” space as unused air rights. (Air rights refer to the space above a parcel of land that belongs to the property owner.) City law might limit building height to, say, fifteen stories. If the developer only builds a ten story building on a site, he will have five stories of undeveloped air rights. The discourse on air rights presents undeveloped (or underdeveloped) sites as not extracting the full height allowed, and therefore reducing the income that could be generated from the most profitable land use.[18] Thus in the Pennsylvania Railroad’s opinion, a vast and open station, although beautiful, represented undeveloped air rights and a financial loss. In 1910, the powerful railroad was wealthy enough to sacrifice million of dollars on a monument and its annual upkeep. The railroad’s objective in 1910 was more about making a statement about their wealth and importance in shaping New York’s urban landscape. However, when 1960s developers measured the value of Penn Station heritage by its precise cash value instead of its intangible cultural value, preserving heritage started to look unrealistically expensive – not just an annual loss of $3.3 million but a loss of several hundred million dollars over several decades in unrealized profits that could have been pulled “out of thin air” so to speak.[19]
Beyond Penn Station, the larger discourse on the commons was also evolving. In previous decades, buildings like Rockefeller Center devoted almost half of the ground-level areas and many rooftops for public use, even though developers in 1930s New York received no tax benefits or compensation from the city for doing so. Other examples include the numerous early Manhattan skyscrapers whose ornamental appearance and decorative silhouettes enliven the urban landscape, even though more ornament outside does not boost the builder’s bottom line of more rentable office space inside. However, with ever-rising land values, corporations were no longer willing by the 1950s to cede increasingly-valuable private land for public use (or even lower-density development) unless compelled to or compensated for doing so. In response, starting in 1961, New York City developed an increasingly complicated system of tax and building incentives for developers to be “civic” and invest in the commons. Examples include corporate green spaces and plazas. In exchange for setting aside a fraction of their land for public use, the developer is allowed to build higher or larger than the laws would otherwise permit. These resulting spaces are in some ways like the interior of old Penn Station, private space that effectively has the appearance of public. These private-public spaces have opening hours, and often prohibit certain behavior like skateboarding, panhandling, and street music performances. Incidentally, city government approved the greatest number of these privately owned public spaces during the city’s near-bankruptcy in the 1980s, when declining budgets motivated city government to surrender power to the private sector.[20] Politicians today speak of contracting the management of public services to for-profit corporations. Privatized services in many states now include water supply, electricity, highways, immigration services, the military, space exploration (through public-private partnerships), and prisons with companies like the Corrections Corporation of America (recently rebranded “Core Civic” in an Orwellian twist). Capitalism and the profit-driven management of the commons is still seen as somehow purifying, making government more efficient, innovative, and flexible.[21] Penn Station’s demolition is an architectural symbol of the limits of historic preservation law, in particular, and the corporate erosion of the commons, in general.
The state and property owners’ expectations of monumental buildings seem fundamentally different from their expectations of traditional monuments like statues and parks. For instance, it is acceptable for the owner of Grand Central Terminal to think of rentable floor space, or for the redevelopers of the World Trade Center memorial to judge proposals based on how much or little land is set-aside for profitable office towers. By contrast, the land Central Park sits on is most certainly many times more expensive in unrealized air rights than the resale value of the timber that currently occupies the land, but that is beside the point because society does not measure the success or failure of the commons by the income it generates. There was a time a century ago when private investment in shaping civic spaces looked something like old Penn Station, Andrew Carnegie’s donated libraries, or even the New York City subway system’s ornamental mosaics. Even ornate nineteenth-century bank lobbies with imposing neoclassical facades have something “civic” about them and share much in common aesthetically with libraries and museums from the time. If only this kind of benevolent attitude toward the commons could be applied today to all manner of other civic institutions: streets, public markets, subways, or the rebuilt future Penn Station.

.

Future Penn Station?

The demolition and replacement of Penn Station sits at an inflection point in the evolving definition of “public space.” Despite public outcry about the demolition of old Penn Station at the hands of powerful private interests, the current station is not publicly owned or managed. The semi-government entity that acquired all of the Pennsylvania Railroad’s assets after the railroad’s 1970 bankruptcy is Amtrak. At least on paper, and although it has never once turned a profit in its over fifty year existence, Amtrak is listed as a corporation with a CEO, stock, and earnings reports. Disgruntled citizens and preservationists cannot speak to or hold them accountable in the same way they can vote out elected officials. As the Metropolitan Transit Authority and Amtrak are both quasi-private “public-benefit corporations,” their executives are all unelected and political appointees. This creates several degrees of separation between those who manage public space and those who use it. What this means for the public is that the spaces the public might see as being public and shared by all – in this case our national rail network and places like the current Penn Station – are effectively private.[22]

.

Proposal for rebuilding Penn Station across the street as the Moynihan Train Hall [23]

.

There seems to be an innate discomfort among city leaders with the idea of investing in the commons without the intention to make some kind of measurable return on investment. New Penn Station’s current owners collect rent from this station’s commercial tenants, the arena at Madison Square Garden, and companies in the office tower above. However unattractive new Penn Station may be, it is at least profitable, which is exactly as the builders who demolished old Penn Station intended.[24] Following this trend, the half-dozen (and counting) proposals over the years to rebuild Penn Station always included a major element of retail shopping and offices. The rebuilt Moynihan Station next door to Penn Station effectively devotes more room to the operations of shopping concourse than rail travel.[25]
However, what made the old Penn Station so aesthetically pleasing was precisely how the design did not consider retail profit. In the interest of aesthetic effect and having impressively large interior spaces, old Penn Station’s retail was segregated to a half-dozen shallow storefronts in the shopping arcade. The architecture was front and center. Rebuilding new Penn Station would require more than money. More importantly, rebuilding would require rethinking the long-held American assumption that extracting profit is compatible with the commons.

.

Train concourse before and after, from the same camera angle

.

Main entrance to waiting room before and after

.

 Perhaps beneath this asphalt parking lot, fragments of the original waiting room floor remain.

.

References

[1] Photo credit: Cervin Robinson and Edward Popko (for the Historic American Buildings Survey). Pennsylvania Station, New York County, NY. Retrieved from the Library of Congress: Digital Collections, www.loc.gov/item/ny0411/. Accessed August 6, 2020.

[2] Photo credit: Myles Zhang. “Excavating Old New York Penn Station.” Myles Zhang, July 9, 2020, https://www.myleszhang.org/2020/07/09/penn-station/. Accessed July 26, 2020.

[3] Kenneth Jackson, Lisa Keller, et al. “Penn Station.” In The Encyclopedia of New York City: Second Edition. New Haven. Yale University Press. 2010. Pp. 987-88.

[4] Martin Tolchin. “Demolition Starts At Penn Station; Architects Picket.” The New York Times. October 29, 1963. Pp 1.

[5] Tom Fletcher. “Penn Station.” New York Architecture, http://www.nyc-architecture.com/GON/GON004.htm. Accessed 26 July 2020.

[6] Allen J. Greenough. “Redeveloping Penn Station.” The New York Times (letter). August 23, 1962.

[7] Hilary Ballon. New York’s Pennsylvania Stations. New York. W. W. Norton & Company. 2002.

[8] George Siedel. “Landmarks Preservation after Penn Central.” Real Property, Probate and Trust Journal. Vol. 17, no. 2. 1982. Pp. 340-356.

[9] Anthony Wood. “Chapter One: The Myth of Penn Station.” In Preserving New York: Winning the Right to Protect a City’s Landmarks. New York. Routledge. 2008.

[10] Myles Zhang. “A History of Historic Preservation in New York City.” Myles Zhang, November 4, 2018, https://www.myleszhang.org/2018/11/04/historic-preservation-and-new-york-city/. Accessed August 6, 2020.

[11] Photo credit: Detroit Publishing Company. “Bird’s-eye view, Penn Station, New York City.” Retrieved from the Library of Congress: Digital Collections, https://www.loc.gov/pictures/item/2016812231/. Accessed August 6, 2020.

[12] Ballon. “The Interior Procession.” In New York’s Pennsylvania Stations. Pp. 60-73.

[13] Andrew Carnegie. “The Gospel of Wealth.” New York. Carnegie Corporation of New York. 2017. (Originally published in the North American Review in 1889.)

[14] Nikolaus Pevsner. “Railway stations.” In A History of Buildings Types. Princeton University Press. 1976. Pp. 225-34.

[15] Carroll Meeks. The Railroad Station. New Haven. Yale University Press. 1964.

[16] Ballon. New York’s Pennsylvania Stations. Pp. 93-101.

[17] Martin Tolchin. “Demolition Starts At Penn Station; Architects Picket.” The New York Times. October 29, 1963. Pp 1.

[18] Philip Weinberg. “Critical Areas: Landmarks, Wetlands, Coastline, Flood Plains, and Takings.” In Environmental Law: Cases and Materials Revised 3rd Edition. Lanham, Maryland. University Press of America. 2006. Pp. 98-108.

Personally, I believe the assumption that “air” is a commercial asset to be bought and sold fundamentally undermines the idea in the commons that air, water, and light are owned collectively by society.

[19] Ballon. New York’s Pennsylvania Stations. Pp. 95-96.

[20] “New York City’s Privately Owned Public Spaces.” NYC: Department of City Planning, https://www1.nyc.gov/site/planning/plans/pops/pops.page. Accessed July 26, 2020.

[21] Brett Heinz. “The Politics of Privatization: How Neoliberalism Took Over US Politics.” United for Fair Economy, September 8, 2017, http://www.faireconomy.org/the_politics_of_privatization. Accessed July 26, 2020.

[22] Fawn Johnson, Rachel Roubein, and National Journal. “Amtrak Has a Trust Problem in Congress: Democrats want to give the rail service more money, and Republicans are demanding more accountability.” The Atlantic, May 13, 2015, https://www.theatlantic.com/politics/archive/2015/05/amtrak-has-a-trust-problem-in-congress/456042/. Accessed July 26, 2020.

[23] Photo credit: Dana Schulz. “Cuomo releases new renderings of Moynihan Station as major construction gets underway.” 6sqft, August 17, 2017, https://www.6sqft.com/cuomo-releases-new-renderings-of-moynihan-station-as-major-construction-gets-underway/. Accessed August 6, 2020.

[24] Ballon. “The New Pennsylvania Station.” In New York’s Pennsylvania Stations. Pp. 153-175.

[25] Justin Davidson. “Every Plan to Fix Penn Station Ranked.” New York Magazine: Intelligencer, January 30, 2020, https://nymag.com/intelligencer/2020/01/every-plan-to-fix-penn-station-ranked.html. Accessed July 26, 2020.

Excavating Old New York Penn Station

Also published by Viewing NYC in May 2019

.

“Through Penn Station one entered the city like a god. Perhaps it was really too much. One scuttles in now like a rat.”
– Vincent Scully

.

View of Penn Station from roof of Macy’s department store c.1910

.

“Human beings, myself included, have an unfortunate tendency to appreciate people and things only after they are gone. Pennsylvania Station is the catalyst for the historic preservation movement.”
– Kenneth Jackson

.

.

The accompanying audio is accurate to what the place sounds like from the locations shown. The audio for old Penn Station is my imaginative reconstruction of how the original station might have sounded like, based on recordings from MoMA. My project was also inspired by this 2015 New York Times article about the subtle influence of sound on how we experience urban space: “Penn Station’s low ceilings suppress sound, which becomes hard to make out, an audible metaphor for its rat’s maze of architecture.”



“You feel that your life is being lost in a room where sound dies. We need reverberation.”
– architect Renzo Piano on the design of the current Penn Station

.

.

.

When New York Penn Station opened in 1910, the Pennsylvania Railroad boasted in advertisements that their vast new station was built of travertine marble from the same ancient Italian quarries as the Coliseum and Pantheon. Old Penn Station was rich in the architectural language of Greece and Rome. The façade comprised a colonnade of massive, Doric columns that stretched almost 450-feet end-to-end; it was inspired from temples on the Greek Acropolis. The main waiting room, at 314-feet-long, 109-feet-wide, and 150-feet-high, was modeled on Rome’s Baths of Diocletian. The project was as much an aesthetic gesture to the emerging City Beautiful Movement as it was a political statement: The Pennsylvania Railroad was here to stay, as permanent as the Penn Station it built.
The finished station, however, was an architectural contradiction. The Neoclassical exterior concealed what was, belowground, an extensive and, at-the-time, hyper-modern system of tunnels, electric trains, and communication systems that conveyed millions of people, baggage, and mail from street-level to each of 21 platforms. Aside from the solid stone columns of the main façade, most of the interior was of thin limestone, marble, and plaster sheets mounted on a metal structural frame. The seeming permanence of the stone walls was a cover for the steel frame and modern technology within on which this Neoclassical stage-set rested.

.

.

Just over fifty years later, on October 28, 1963, demolition began. The Pennsylvania Railroad, burdened with debt and aging infrastructure, was selling off its most profitable real estate assets – its land, buildings, and equipment – to stay afloat until it declared bankruptcy by 1970. Through the same two Hudson River tunnels that building materials for the original Penn Station were delivered, some of the same rubble now passed. Much of this rubble was carted off and dumped in the New Jersey Meadowlands adjacent the tracks where commuter trains still pass. The Pennsylvania Railroad used, quite literally, the station’s technology to cannibalize itself, and as the foundations for the new, and current, Penn Station.
Searching for remnants of old Penn Station, I found historic photos from the New York Public Library, Historic American Buildings Survey, and Library of Congress. I returned to the same locations in fall 2019 to re-photograph these images from the identical camera angles. The resulting and visible ghost of the lost Penn Station presents a strong-clear vision of what Penn Station used to be, and by extension, what it could return to, given financial commitment and political will.

.

Train concourse: past and present from the same location

.

The current subterranean warrens represent a clean break from what was here before. As long as Madison Square Garden chokes Penn Station for air and light from above, the current lightless and oppressive Penn Station is here to stay. The current station’s cheap ceilings of corrugated metal, garish electric signage, and exposed concrete floors ironically proved more durable than the Roman marble and limestone of old. The current station is not so fleeting and has, in fact, existed longer on this site than the station before it.
Surprising still is how, for many New Yorkers, it seems inconceivable that the permanent and imposing appearance of the original station could, one day, simply vanish without a trace. This old station is more dream than reality, and it seems almost impossible to imagine the current arrangement as having anything to do with what came before. So little of the original station – and the pride in civic life and New York City this station stood for – remains visible. Interestingly, more of the original architectural fabric survives belowground than meets the eye aboveground.

.

View from corner of 31st Street and 7th Avenue in 1962 and 2019. The structure is unrecognizable aboveground.

.

.

.

.

32nd Street entrance to waiting room in 1962 and 2019
The southeast corner of the still-standing General Post Office is in both frames, in the far left hand distance.

.

.

.

In the five years that demolition and rebuilding lasted (from 1963 to 1968), Penn Station remained in active service. While builders demolished the old station above, commuters continued to pass by on the platforms and corridors below. For this brief moment, the two buildings lived side-by-side, until the present building swallowed almost all visible traces of the past. In spite of this loss, the confusing floor plan of the current Penn Station has much to do with remaining traces of the original. Column for column and void for void, the current Penn Station is built within the fabric of the original. The old Penn Station, completed 1910, had 21 tracks on 11 platforms. The new Penn Station has 21 tracks on 11 platforms. In the demolition process, not one track or platform moved. In the five-year re-construction process, none of the tracks and platforms were moved, and most of the stairs between concourse and track-level survived. This similarity enables us to situate parts of the old structure in relation to the new.

.

Frame of new Penn Station rises simultaneous to the demolition of the old c.1963-68
Passengers in train concourse as new structural frame divides them from the soon-to-be-demolished glass canopy of the old station.

.

Train concourse before and after insertion of the new structural frame, from the same camera angle

.

.

.

The above cross-section of old Penn Station’s waiting room shows the extent of change. The orange line indicates the elevation at ground-level to which the architectural fabric of the old building was demolished. Above this line, nothing of Penn Station survives. Below this line, most of the original structure, tracks, infrastructure, stairwells, and the general contours of the original rooms survive, except now hidden.
After the Roman Empire collapsed, its architectural monuments to empire and power fell into disuse; many were repurposed for more humble and practical purposes. The Coliseum became a stone quarry, the Roman Senate House a humble church, and the Theatre of Marcellus a medieval fortress. New purposes were developed in the shells of old monuments. When a building is reused and altered but still bears visible traces of its earlier form, architectural historians call this creation a palimpsest. A palimpsest is neither of the present nor of the past; it is a mixture of both. For instance, the two square fountains of the 9/11 Memorial in Lower Manhattan mirror the locations of the now-vanished Twin Towers. For a relatively modern and young city in world terms, Penn Station is New York City’s largest palimpsest.

.

Shopping arcade in 1911 and 2019

.

.

View from 7th Avenue shopping arcade into the waiting room in 1911 and 2019

.

“Cutaway illustrating the principle of adaptive reuse.” Drawing by architectural children’s book illustrator, David Macaulay, proposes to discard the “non- functional” spaces of the medieval cathedral by erecting a Styrofoam drop ceiling just above the floor. Everything above – light, soundscape, and ornament is “superfluous” to the cathedral’s function.

The oppressively low ceilings of the current station are the structural division between the public areas belowground and the now private (formerly public) areas aboveground. These ceilings also align to the border between the infrastructure of the original station that survives and the architectural fabric that was lost.
The Pennsylvania Railroad made the decision that made the most economic sense: to keep the infrastructure beneath and merely decapitate the “non-functional” aesthetics of the soaring ceilings and open spaces aboveground. This was valuable land that could be put to more profitable use. Into these empty “air rights,” the corporation could insert Penn Station’s new functions of Madison Square Garden and office towers that would, at last, generate additional income. While exploring the station, I discovered this palimpsest valued the practical and made absolute economic sense: Who needs to enter the city on the scale of a titanic-sized god when humans require spaces no higher than 8-feet-high to pass through?

.

A cathedral with a drop ceiling

.

.

The shopping arcade in 1911 and 2019
Statue of Samuel Rea is in the shadows.

.

President Samuel Rea

The nuances of this palimpsest become clearer from inside. Passengers entering the old station proceeded down a long shopping arcade to the waiting room and platforms. What was once public space is now the private lobby of the commercial offices aboveground. On the right hand side, in the shadows of the private lobby, stands a statue of Samuel Rea, president of the Pennsylvania Railroad. A century ago, Rea stood at the entrance and welcomed passengers and the public; he now stands and watches the corporate clients and office workers. In old Penn Station, an inscription beneath announced his name and title. In the current location, Rea is out of place and has no relationship with his surroundings; the once prominent inscription is almost invisible on the new tablet behind him.

.

Statue of Samuel Rea is in the left hand niche.
Almost stone for stone, the location of the current waiting room escalator mirrors the location of the original.

.

.

Main entrance to waiting room: The left hand niche contains the statue of Alexander Cassatt, Pennsylvania Railroad president during construction.

.

.

The waiting room, once the largest indoor public space in New York City, is now a parking lot.

.

From the street-level arcade, passengers descended into the cavernous waiting room, sunken a few feet belowground. While the room itself is gone, the contours of this room survive in the general footprint of the slightly sunken parking lot that now occupies the site. What was once public space is now private and patrolled by Madison Square Garden security guards who forbade me from standing at this location with my camera.

.

Perhaps, beneath this asphalt parking lot, fragments of the original waiting room floor remain.

.

.

Train Concourse

.

.

Train concourse, past and present.
White cutouts on the drop ceiling mirror the former locations of the demolished skylights hundreds of feet above.

.

.

.

.

.

.

This part of the train concourse is now the VIP entrance for spectators at Madison Square Garden.

.

The design problems with the current Penn Station are similar to those of old Penn Station: too few tracks, too many passengers, confusing circulation, and outdated infrastructure. After all, it is not the engineering and infrastructure that set these two buildings apart, as brick-for-brick and beam-for-beam, the 1960s rebuilding did not generally alter the areas belowground. This early-twentieth-century infrastructure was, after all, designed to handle no more than 200,000 passengers-per-day, and yet now struggles under the burden of 650,000-per-day. Instead, it is the envelope around this infrastructure that was rebuilt in the 1960s, and whose loss the public and historians now mourn.

.

.

At track-level, the railroad ties, location of the third rail, and support columns are largely original to 1910. The columns in the foreground were added in the 1960s to support the weight of Madison Square Garden. The columns in the distance are original to 1910. The 1960s modernist buildings above conceal below what is, in essence, mostly early-twentieth-century infrastructure.

.

View from Track Six

.

Generations of New Yorkers hoped Penn Station would one day be restored with an architectural monument befitting New York City and the Western hemisphere’s busiest train station. In addition to rebuilding the General Post Office next door, other proposals over the years have called for rebuilding Penn Station exactly as it appeared before, or imagining a futuristic Penn Station emerging from the structural shell of the current Madison Square Garden, aptly entitled “Penn Station Palimpsest.” Precedent exists for both proposals. Some post World War II cities rebuilt their monuments and bombed out city centers exactly as they appeared before (such as Dresden and Warsaw), while others incorporated the rubble of the lost buildings into a modern building (such as Coventry Cathedral in England and Kaiser Wilhelm Memorial Church in Berlin). What we miss about old Penn Station was not the infrastructure, operations, or even the building itself, but rather the way this architecture made us feel dignified, and which we feel no longer.

Sticky problems with mapping historical New York City

Author’s time-lapse of Lower Manhattan’s street network development from 1609-2020

With help from digital and spatial mapping software, urban historians and geographers are examining city growth over time. Time-lapse evolutions are proliferating online of street network development in cities like New York City, Barcelona, London, and Berlin.
In most time-lapse studies, geographers encounter problems with lack of data. The older the city, the less data there exists about pre-modern population densities, demographics, and street networks. This lack of data is a problem when mapping the geographies of older cities.
A way around this problem is to look at street network development as a proxy for population size. The more streets there are built, the more people this city should have, the logic follows. In theory, this seems to work because cities with larger populations require more streets and occupy more built-up area. Knowing how much surface area a city occupies, coupled with knowing the average size and number of occupants in a typical block or building, allows a simple calculation of total population (people/acre x surface area). In addition, more historical data exists about street networks (from maps) than exists about population and demographics (from the census).
The problem with this method of using streets as a proxy for demographics is that cities that occupy more surface area and with more streets do not necessarily have more people. There are several reasons for this:
  • Available land: Some cities are built in harder geographies where acquisition of new land for development is prohibitively difficult to acquire, such as Venice. Manhattan’s high density and land values descend, of course, from a demand for housing that far exceeds supply on an island bordered by water.
    For instance, Oklahoma City covers 621 square miles with a 2018 population of only 650,000. New York City covers 302.6 square miles (half the area of Oklahoma City) and has a 2018 population of 8.4 million (thirteen times the population of Oklahoma City). Despite the major differences between these two cities – in population and surface area – the sum total of all streets if they were lined up end to end to form a continuous road is about the same for both cities. Similarly, the Manhattan grid is identical with the same street widths and block sizes from end to end of the island, even though population density in buildings within this grid varies from zero people per acre to over 200 per acre. Flexible street networks support any variety of housing types and densities, which means that street maps alone cannot reveal all the demographic nuances.
  • Zoning: Some municipalities are stricter than others in enforcing discrete and different land uses for residential, commercial, industrial, and mixed-use. The legal landscape of Manhattan has evolved significantly since the first zoning laws in 1916 restricted building height and density. Since then, city government has more clearly articulated rules about minimum apartment size, ventilation, fire escapes, and water supply. City government has also pulled industrial (and often more polluting) land uses away from residential areas in the name of health and safety.
    Although few of these legal and zoning changes are explicitly imprinted on the street network, they have a tangible and important impact on the quality of urban life. This zoning has largely resulted in lower population density because of restrictions on landlords cramming hundreds of people into the smallest space possible for the maximum profit. Now, over 40% of all buildings on Manhattan could not be built today for violating NYC’s zoning code for at least one reason. For instance, most buildings in neighborhoods like West Village and Lower East Side have not changed in a century; there is limited demolition and reconstruction every year. However, population density has significantly fallen as apartments grow larger and rooms formerly designed for multiple people in one room now only have one or two occupants. Even if the buildings and streets don’t change, the ways they are occupied can and do. In other words, changing in zoning and land use are not necessarily visibly imprinted on the plan of streets, particularly if those streets are rigid grids.
  • Transportation patterns: This is the biggest factor encouraging extensive and rapid street network development with low population density – i.e. sprawl. Before the nineteenth-century inventions of railways and streetcars, and the twentieth-century’s auto-based suburbanization, transportation and commuting were prohibitively difficult. People needed to live near to where they worked in what was largely a pedestrian and walking city on unpaved streets. Transportation challenges caused urban growth to be dense and built-up near to places of employment. As a result, many cities like Paris and London might appear small on old maps and occupy only a few square miles pre-1800, even though their population and economic importance were far larger than their surface area on maps leads one to assume. Again, less developed street networks and a smaller surface area of urban development does not neccessarily mean the corresponding city is less culturally or economically important.
Before the introduction of subways in the early twentieth century, the difficulties of commuting greater distances over land and water drove a denser form of urbanism than today. Manhattan, by 1900, had over 2.3 million residents in comparison to only 1.6 million in 2020. These people were crowded into dense blocks with upward of half a million people per square mile. Over the following century, although Manhattan’s population declined by 700,000 people, the street network today is almost identical to a century ago – no smaller and no larger despite major shifts. These shifts in density and demographics simply do not show up on conventional street maps.
My animation below shows the evolution of Manhattan’s built-up area and population density from 1800 to 2010. Notice the steady upward march of street development versus the sudden spike in population density on the Lower East Side in 1910 at over 300,000 people per square mile (in contrast to less than 90,000 in 2010). For every decade after the construction of subways, there has been more urban sprawl, and the island’s population density has fallen. Notice how fluctuations in population density operate semi-independently of street-network development.

.

Modified from Shlomo Angel and Patrick Lamson-Hall’s NYU Stern Urbanization Project,
here and here.

The animation on the left tells one story of continuous and north-moving development, while the animation on right tells a more nuanced story of population density. The challenge is to find a graphic representation that tells both stories, as neither visualizes all the nuances of urban history.

.

Possible Solutions

Discussing this problem of street networks with professor Kenneth Jackson, he suggested looking at building Floor Area Ratio (abbreviated FAR), which is the building height and size relative to the amount of land the building occupies. A skyscraper has high FAR. A trailer park has low FAR.
This method of representing urban growth would, in theory, produce three sets of maps: 1) a map of street network development; 2) a density map of people living per square mile; 3) a map of building height and size. This would complicate things but produce a far more accurate representation of urban growth (how to represent this and if enough data exists is another matter).
These three factors – streets, FAR, and population density – act semi-independently of each other. Different urban typologies will share a different mixture of these three factors. Only through analysis of the relationship between these three factors can one begin to understand the underlying demographic, economic, zoning, and historical differences between neighborhoods. For instance:
  • Downtown commercial district like Lower Manhattan: low population density but high FAR. In this case, FAR operates in inverse proportion to residential population density. Buildings can be dozens of stories but have no residents. There is a high density of tall buildings (i.e. high FAR) but low population density.
  • Slum like South Bronx in the 1980s: extensive (though poorly-maintained) street network development, high density, but low FAR because slum dwellings are typically informal without the construction quality required to build high. Buildings might be fewer than six stories and without elevators, as in the Lower East Side, but can contain hundreds or thousands of residents over the tenement’s lifespan. There is low density of tall buildings (i.e. low FAR) but high population density.
  • Suburb like Forest Hills, Queens: extensive (and well-maintained) street network development, low density, and low FAR. In wealthier suburbs, in particular, FAR is kept prohibitively low. Restrictions on minimum lot size required to build, minimum house size, and legal hurdles on subdividing larger lots into smaller ones all serve to enforce a certain quality and price of residential construction that often prices-out lower-income communities of color. There is low density development with numerous green spaces between free-standing homes (i.e. low FAR) and low population density.

.

Left: NYC population by day in 2015. Right: NYC population by night in 2015. The population doubles by day.

.

The two density maps above are one illustration of FAR and help nuance Manhattan’s historical development. Areas with the highest FAR tend to be commercial areas with daytime office workers and commuters. The left map shows the daytime population density of the over two million commuters. The areas with highest worker density neatly map onto the same areas of Lower Manhattan and Midtown with skyscraper clusters (i.e. high FAR). The right map shows nighttime population density of residential areas, which also neatly map onto areas with generally lower building height and density (i.e. low FAR). Notice the gray-colored zones in Lower Manhattan and Midtown with an almost zero nighttime population density, which are incidentally the areas with the highest daytime population density and the tallest buildings.
In twenty-first-century New York City, it is quite easy to examine the relationship between these three factors – street network, population density, and FAR – as the datasets are readily available from NYC Open Data. Yet, this all becomes more difficult – perhaps prohibitively difficult – for historical mapping. Calculating FAR for historical Manhattan is certainly possible through scrutinizing digitized historical Sanborn fire insurance maps that go so far as to specify building footprint, materials, and height. However, at the moment, this data is not easily accessible. Historical building footprints and FAR must be calculated through manually scanning, tracing, and inputting data from the New York Public Library’s collection. This must be done for thousands (even millions of buildings) over hundreds of years.
As technology improves, it may be possible in a few decades to translate historical maps into data files that reveal FAR. If historical maps could be scanned and immediately transformed from image files to geospatial data files, the possibilities of using historical maps to inform contemporary research are endless. If and when there is the data on historical FAR, it may be possible to create a new paradigm for studying urban history.

.

New York City Population Density in 1900

Author’s illustration based on population per municipal ward from 1900 Federal census

Architecture of Redemption?

Contradictions of Solitary Confinement
at Eastern State Penitentiary

Master’s thesis at Cambridge University: Department of Art History & Architecture
Developed with Max Sternberg, historian at Cambridge University

.

.

The perfect disciplinary apparatus would make it possible for a single gaze to see everything constantly. A central point would be both the source of light illuminating everything, and a locus of convergence for everything that must be known: a perfect eye that nothing would escape and a centre towards which all gazes would be turned.
– Michel Foucault

.

Abstract

Prison floor plan in 1836

In the contemporary imagination of prison, solitary confinement evokes images of neglect, torture, and loneliness, likely to culminate in insanity. However, the practice originated in the late-eighteenth- and early-nineteenth-century as an enlightened approach and architectural mechanism for extracting feelings of redemption from convicts.
This research examines the design of Eastern State Penitentiary, built by English-born architect John Haviland from 1821 to 1829 in Philadelphia, Pennsylvania. This case study explores the builders’ challenge of finding an architectural form suitable to the operations and moral ambitions of solitary confinement. Inspired by Jeremy Bentham’s panopticon, Haviland’s design inspired the design of over 300 prisons worldwide. With reference to primary sources and to philosophers Jeremy Bentham and Michel Foucault, this research interrogates the problematic assumptions about architecture and human nature encoded in the form of solitary confinement practiced at Eastern State Penitentiary, which has wider implications for the study of surveillance architecture.

.

Click here to read

Opens in new window as PDF

.

Acknowledgments

I am indebted to Max Sternberg for his attentive guidance throughout this research, and his support of my experience in providing undergraduate supervisions at Cambridge. I am grateful to Nick Simcik Arese for encouraging me to examine architecture as the product of labor relations and relationships between form and function. I am inspired by Alan Short’s lectures on architecture that criticize the beliefs in health and miasma theory. My research also benefits from co-course director Ronita Bardhan. Finally, this research is only possible through the superb digitized sources created by the staff of Philadelphia’s various archives and libraries.
I am particularly indebted to the guidance and friendship of Andrew E. Clark throughout my life.
The COVID-19 pandemic put me in a “solitary confinement state-of-mind,” allowing me to research prison architecture from a comfortable confinement of my own.

.

Related Projects

.

Digital Reconstruction
of Eastern State: 1836-1877

Digital Reconstruction
of Jeremy Bentham’s Panopticon

Exhibit on Prison Design
Research begun before MPhil

.



The Berlin Evolution Animation

Abstract: The Berlin Evolution Animation visualizes the development of this city’s street network and infrastructure from 1415 to the present-day, using an overlay of historic maps. The resulting short film presents a series of 17 “cartographic snapshots” of the urban area at intervals of every 30-40 years. This process highlights Berlin’s urban development over 600 years, the rapid explosion of industry and population in the nineteenth-century, followed by the destruction and violence of two world wars and then the Cold War on Berlin’s urban fabric.

.

.

.

Animation der Wandlung Berlins

Zusammenfassung: Auf der Grundlage von historischen Karten visualisiert die „Animation der Wandelung Berlins“ die Entwicklung des Straßennetzwerks und der Infrastruktur Berlins von 1415 bis heute. In diesem kurzen Video wird eine Serie von 17 „kartographischen Momentaufnahmen“ der Stadt in einem Intervall von 30 – 40 Jahren präsentiert. Dadurch wird die Entwicklung der Stadt Berlin über 600 Jahre, das rapide Wachstum der Industrie und Bevölkerung im 19. Jahrhundert, die Zerstörung und Gewalt der zwei Weltkriege und abschließend des Kalten Krieges auf Berlins Stadtbild verdeutlicht.

German translations by Richard Zhou and Carl von Hardenberg

.

Year, Event and Estimated Population
1415 – Medieval Berlin – 7,000
1648 – Thirty Years War – 6,000
1688 – Berlin Fortress – 19,000
1720 – Rise of Prussian Empire – 65,000
1740 – War with Austria – 90,000
1786 – Age of Enlightenment – 147,000
1806 – Napoleonic Wars – 155,000
1840 – Industrial Revolution – 329,000
1875 – German Empire – 967,000
1920 – Greater Berlin – 3,879,000
1932 – Rise of Fascism – 4,274,000
1945 – Extent of Bomb Damage – 2,807,000
1950 – Germania – World Capital
1953 – Recovery from War – 3,367,000
1961 – Berlin Wall – 3,253,000
1988 – A City Divided – 3,353,000
Contemporary – A City United
Census year
Jahr, Ereignis und geschätzte Anzahl von Bewohnern
1415 – Berlin im Mittelalter – 7,000
1648 – Der Dreißigjährige Krieg – 6.000
1688 – Die Festung Berlin – 19.000
1720 – Der Aufstieg des Königreichs Preußen – 65,000
1740 – Der Österreichische Erbfolgekrieg – 90.000
1786 – Das Zeitalter der Aufklärung – 147.000
1806 – Die Koalitionskriege – 155.000
1840 – Die industrielle Revolution – 329.000
1875 – Das Deutsche Kaiserreich – 967.000
1920 – Groß-Berlin – 3.879.000
1932 – Der Aufstieg des Faschismus – 4.274.000
1945 – Die Spuren des 2. Weltkrieges – 2.807.000
1950 – Germania – Welthauptstadt
1953 – Deutsches Wirtschaftswunder – 3.367.000
1961 – Die Berliner Mauer – 3.253.000
1988 – Eine geteilte Stadt – 3.353.000
Heute – Eine wiedervereinte Stadt
Jahr der Volkszählung

.

Methodology and Sources

I chose not to represent urban development before 1415 for three reasons: Firstly, there are too few accurate maps of the city before this time. Secondly, I needed to find accurate maps that had visual style consistent with later years, to enable easier comparison of development over time. Thirdly, the extent of urban development and population is limited (fewer than 10,000 Berliners).
There are numerous maps showing Berlin’s urban growth. Yet, few of them are drawn to the same scale, orientation and color palette. This makes it more difficult to observe changes to the city form over time. Fortunately, three map resources show this development with consistent style.
  1. The Historischer Atlas von Berlin (by Johann Marius Friedrich Schmidt) published 1835 represents Berlin in the selected years of: 1415, 1648, 1688, 1720, 1740, 1786. This atlas is available, free to view and download, at this link.
  2. After the year 1786, I rely on three books from cartographer Gerd Gauglitz:
    Berlin – Geschichte des Stadtgebietsin vier Karten
    Contains four beautiful maps of Berlin from 1806, 1920, 1988 and 2020. Read article.
    Berlin – Vier Stadtpläne im Vergleich
    Contains four maps from 1742, 1875, 1932 and 2017. Read article.
    Berlin – Vier Stadtpläne im VergleichErgänzungspläne
    Contains four maps from 1840,1953, 1988 and 1950. The last map from 1950 is purely speculative and shows Berlin as it would have looked had Germany won WWII and executed Albert Speer’s plans for rebuilding the city, named “Germania.” Read article.
    Gerd Gaulitz’s three map books can be purchased from Schropp Land & Karte.
  3. I also show the estimated extent of WWII bomb damage to Berlin. This map is sourced from an infographic dated 8 May 2015 in the Berliner Morgenpost. View original infographic. This infographic is, in turn, based on bombing maps produced by the British Royal Air Force during WWII (and Albert Speer’s c.1950 plan for Berlin).
Below is an interactive map I created of the Berlin Wall’s route and the four Allied occupation areas:

.

.

Population statistics in the 17 “cartographic snapshots” are estimates. The historical development of Berlin’s population is known for a few years. For other years, the population is estimated with regards to the two censuses between which the year of the “snapshot” falls.

New York City Water Supply: Animated History

Developed with Gergely Baics, urban historian at Barnard College

.

New York City has some of the world’s cleanest drinking water. It is one of only a few American cities (and among those cities the largest) to supply completely unfiltered drinking water to nine million people. This system collects water from around 2,000 square miles of forest and farms in Upstate New York, transports this water in up to 125 miles of buried aqueducts, and delivers one billion gallons per day, enough to fill a cube ~300 feet to a side, or the volume of the Empire State Building. This is one of America’s largest and most ambitious infrastructure projects. It remains, however, largely invisible and taken for granted. When they drink a glass of water or wash their hands, few New Yorkers remind themselves of this marvel in civil engineering they benefit from.
This animated map illustrates the visual history of this important American infrastructure.

.

Sound of water and ambient music from Freesound

New York City is surrounded by saltwater and has few sources of natural freshwater. From the early days, settlers dug wells and used local streams. As the population grew, these sources became polluted. Water shortages allowed disease and fire to threaten the city’s future. In response, city leaders looked north, to the undeveloped forests and rivers of Upstate New York. This began the 200-year-long search for clean water for the growing city.

.

Credits

Gergely Baics – advice on GIS skills and animating water history
Kenneth T. Jackson – infrastructure history
Juan F. Martinez and Wright Kennedy – data

.

Interactive Map

I created this animation with information from New York City Open Data about the construction and location of water supply infrastructure. Aqueduct routes are traced from publicly-available satellite imagery and old maps in NYPL map archives. Thanks is also due to Juan F. Martinez, who created this visualization.
Explore water features in the interactive map below. Click color-coded features to reveal detail.

.

Watersheds   Subsurface Aqueducts   Surface Aqueducts   Water Distribution Tunnels   City Limits

.

▼ For map legend, press arrow key below.

.

Sources

.
For such an important and public infrastructure, the data about this water supply, aqueduct routes, and pumping stations is kept surprisingly secret in a post 9/11 world. However, the data presented here is extracted from publicly-available sources online, and through analysis of visible infrastructure features on satellite imagery when actual vector file data or raster maps are unavailable from NYC government.
.
Contemporary Maps
NYC System and Shapefiles – Juan F. Martinez
Watershed Recreation Areas – NYC Department of Environment Protection (DEP)
General System Map – NY State Department of Environmental Conservation (DEC)
.
Historic Maps
.
Texts
Water Supply Fast Facts – NY State DEC
Encyclopedia of the City of New York – Kenneth T. Jackson
.
Animation music – Freesound
Audio narration – Myles Zhang
